Sinotruk Howo Used 10wheels 6x4 336hp High Power Water Tank Truck
Used Water Tanker Truck Features:
20 Cubic Meter Sinotruk Howo used water tanker truck is made by adopting an automatic assembly line
including charging, jointed panel automatic welding, seal head spin forming, and other advanced tank production
technologies. In general, the tanker is made of high-quality carbon steel plate. If required, we can also use SUS
304 stainless steel. Howo 6x4 water tank truck has the following components: anti-corrosive tank, communicating
vessels, dedicated self priming spray pump, pipe network, spraying exit, working platform, chassis, etc.
Howo used water tanker truck adopts a high-quality water spraying pump, which is of high-power. Water can be
sprayed from the front, back and both sides.It is equipped with a suction pipe, fire fighting joint, and automatic
flow valve, etc. Rear working platform is fitted with spraying pipe and the water sprayed out can be of heavy
sprinkle, moderate sprinkle, drizzle, fog, among other options.
USED WATER TANKER TRUCK SPECIFICATIONS
| Truck Model |
ZZ1257N4347A1 |
| Truck Brand |
SINOTRUK –HOWO |
| Driving Style |
Left Hand Driving |
| Tank body volume |
20M3 |
| Approaching angle/Departure angle(°) |
19/26 |
| Overhang(front/rear) (mm) |
1500/1739 |
| Wheel base (mm) |
4350+1350(mm) |
| Max speed(km/h) |
75 |
| Maximum gradeability (%) |
40 |
| Minimum ground clearance(mm) |
314 |
| Minimum turning circle (m) |
20 |
| Curb weight(kg) |
12290 |
| Loading Weight(kg) |
25000 |
| Fuel tanker capacity(L) |
300 |
| Fuel consumption(L/km) |
28L/100 km |
| Clutch |
Single-plate dry clutch Φ430mm |
|
Engine Model
(Steyr technology, made in China)
|
Fuel type |
Diesel |
| |
Horse Power, max(kw/rpm) |
336HP |
| |
Emission |
EURO II |
| |
Model |
WD engine 4 Stroke Direct Injection Diesel |
| |
Bore |
126mm |
| |
Stroke |
130mm |
| |
Compression ratio |
29.8hp/l |
| |
Specific fuel consumption |
195g/kwh |
| Transmission |
Model |
HW19710 |
|
Brake system
|
Service brake |
Dual circuit compressed air brake |
| |
Parking brake |
spring energy, compressed air operating on rear wheels
|
| |
Auxiliary brake |
Engine exhaust brake |
|
Steering system
|
Model |
ZF8098 Hydraulic Steering with power assistance. |
| Front axle |
HF7, Steering with double T-cross section beam |
| Rear axle |
ST16, Pressed axle housing, central double reduction with differential locks between axles and wheels REAR AXLE RATIO: 5.73 |
| Color |
Optional (White ,Red ,yellow ) |
| Tyre |
295/80R22.5 x 11pcs
(with one spare tyre)
|
| Ground Clearance |
Ground Clearance of front spray nozzle: 470mm; |
|
Electrical system
|
Battery |
2X12V/165Ah |
| |
Alternator |
28V-1500kw |
| |
Starter |
7.5Kw/24V |
| Cab |
HW76, single sleeper with air conditioner
all-steel forward control,55ºhydraulically tiltable to the front, 2- arm windscreen wiper system with three speeds, laminated windscreen with casted-in radio aerial, hydraulically damped adjustable driver’s seat and rigid adjustable co-driver’s seat, with heating and ventilating system, outer sun visor, adjustable roof flap, with stereo radio/cassette recorder, safety belts and adjustable steering wheel, air horn, with 4-point support fully floating suspension and shock absorbers
|
|
