Refurbished Used Sino Howo 10 Tire Construction Tipper Trucks
Used Howo Trucks Quality
Now there are many different prices of used HOWO dump truck in the international market, quality also different. Many customers complained to us, the used trucks they bought from other suppliers cannot even be used once they received the trucks. Based on this condition, we make higher quality standard for used HOWO dump trucks, which can make sure the trucks running in a good way.
Used Howo Trucks Inspection
1. Engine: To make sure the engine starts normally, no oil leakage, no emitting black smoke, blue smoke or white smoke.
2. Transmission: To make sure the transmission gear is in correct position and functioning well.
3. Axle: To make sure no leaking oil and drive normally.
4. Frame: To make the frame is not deformed.
5. To make sure headlights, wiper, A/C and other parts can work normally.
PARAMETERS OF USED HOWO TRUCKS
| Truck Model |
ZZ3257N3847C |
| Driving Style |
Left Hand Driving(Right Hand Driving is optional) |
| Dimension(Lx W x H)(unloaded)(mm) |
8265x2496x3490 |
| Cargo body size (L*W*H, mm) (mm) |
5400x2300x1500mm 18.63m3 |
| Cargo thickness(mm) |
Bottom:8mm, Side:6mm |
| Lift type of Carriage |
Middle lifting system |
| Approaching angle/Departure angle(°) |
20/26 |
| Overhang(front/rear) (mm) |
1540/1750 |
| Wheel base (mm) |
3625+1350 |
| Max speed(km/h) |
78 |
| Curb weight(kg) |
12500 |
| Loading Weight(kg) |
30,000 |
| Fuel tanker capacity(L) |
300 |
| Clutch |
Single-plate dry clutch Φ430mm |
| Engine Model |
Fuel type |
Diesel |
| Horse Power, max(kw/rpm) |
371HP(375HP,420HP) |
| Emission |
EURO II |
| Model |
WD615.47,water-cooled,four strokes,6 cylinders in line with water cooling , electric injection |
| Transmission |
Model |
HW19710, 10 forwards and 2 reverse |
| Brake system |
Service brake |
Dual circuit compressed air brake |
| Parking brake |
spring energy, compressed air operating on rear wheels |
| Auxiliary brake |
Engine exhaust brake |
| Steering system |
Model |
ZF8118 hydraulic steering with power assistance |
| Front axle |
HF9, Steering with double T-cross section beam |
| Rear axle |
HC16, Pressed axle housing, central double reduction with differential locks between axles and wheels |
| Color |
Optional (White, Red, yellow ) |
| Tyre |
12.00R20 radial tires, 10+1pcs |
| Electrical system |
Battery |
2X12V/165Ah |
| Alternator |
28V-1500kw |
| Starter |
7.5Kw/24V |
| Cab |
HOWO76 Cab , single sleeper with air conditioner |
|
Bulk Ship
Flat Rack Container
Ro-Ro Ship
Our Workshop:
Cab Details:
HW76, One Sleeper with A/C. Refurbished cabin with new seats, new sleeper, new dashboard, new interior,etc
Export Records:
Our main business area is Africa, about 40-50% of our total sales volume.
8 units of Dump truck exported to Burkina Faso,TETACAR company
5 units of Dump Truck exported to Nigeria,CA transport company
20 units of Dump truck to Malawi ,ETS Company
5 units of Dump Truck exported to Dubai ,ATM OCT Company
