371HP 18.6M3 Bucket Used Howo 6x4 Tipper Truck With 12.00R20 Tire
Used Howo Trucks Features
Used SINOTRUK HOWO 6x4 dump truck is used for construction and other mining or transportation work. Truck cargo box adopts high strength steel material Q345B or Q375, which can transport sand, gravel, stone, etc. And howo used dump truck can climb steep slopes with strong engine horse power.
Business Scope
Our main products include full series products of CNHTC(HOWO,STR,Golden Prince,etc.) used trucks, such as dump truck, tractor truck, concrete mixer truck, sprinkler truck, water/Oil tank truck, truck mounted crane, concrete pump truck.etc, and spare parts for them.
USED HOWO TRUCKS SPECIFICATIONS
| Truck Model |
ZZ3257N3647A |
| Driving Style |
Left Hand Driving(Right Hand Driving is optional) |
| Dimension(Lx W x H)(unloaded)(mm) |
8265x2496x3490 |
| Cargo body size (L*W*H, mm) (mm) |
5400x2300x1500mm 18.63m3 |
| Cargo thickness(mm) |
Bottom:8mm, Side:6mm |
| Lift type of Carriage |
Middle lifting system |
| Approaching angle/Departure angle(°) |
20/26 |
| Overhang(front/rear) (mm) |
1540/1750 |
| Wheel base (mm) |
3625+1350 |
| Max speed(km/h) |
78 |
| Curb weight(kg) |
12270 |
| Loading Weight(kg) |
30,000 |
| Fuel tanker capacity(L) |
300 |
| Clutch |
Single-plate dry clutch Φ430mm |
| Engine Model |
Fuel type |
Diesel |
| Horse Power, max(kw/rpm) |
371HP(375hp,420hp is optional) |
| Emission |
EURO II(Euro3, Euro4 is optional) |
| Model |
WD615.47,water-cooled,four strokes,6 cylinders in line with water cooling , electric injection |
| Transmission |
Model |
HW19710, 10 forwards and 2 reverse |
| Brake system |
Service brake |
Dual circuit compressed air brake |
| Parking brake |
spring energy, compressed air operating on rear wheels |
| Auxiliary brake |
Engine exhaust brake |
| Steering system |
Model |
ZF8118 hydraulic steering with power assistance |
| Front axle |
HF9 , Steering with double T-cross section beam |
| Rear axle |
HC16, Pressed axle housing, central double reduction with differential locks between axles and wheels |
| Color |
Optional (White ,Red ,yellow ) |
| Tyre |
12.00R20 radial tires, 10+1pcs |
| Electrical system |
Battery |
2X12V/165Ah |
| Alternator |
28V-1500kw |
| Starter |
7.5Kw/24V |
| Cab |
HOWO76 Cab , single sleeper with air conditioner |
|
High configuration of renovation
1. SINOTRUK HOWO 6x4 30 Ton dump truck cargo box is 100% new.
2. Cargo box material adopts high strength steel Q345B.
3. With mudguard, mark lamp, lamp, fuel tank and battery protect cover.
4. Suitable for loading sand, gravel etc.
5. U shape and rectangle cargo box available.
6. Front or Middle hydraulic lifting system, famous brand.
7. Computer control automatic welding for the truck manufacturing.
8. Linglong or Triangle brand 12.00R20 tyre.
Our Workshop:
New electric circuit and air circuit ensure whole truck work smoothly and normally.
Completely new Linglong or Triangle brand 12.00R20 tire, very famous and popular in Africa, even DANGOTE fleet equipped with Triangle brand.
Export Record:
Our main markets are African countries, like Nigeria, Ghana, Tanzania, Ethiopia,etc. About 50% market share.
