China High Quality Second Hand Tipper Trucks With Daily Maintenance
Used Howo Dump Truck Introduction
Dump truck refers to a vehicle that unloads cargo by hydraulic or mechanical lifting. It is composed of automobile chassis, hydraulic lifting mechanism, cargo compartment and power take-off device. As a second hand howo dump truck supplier, we will do refurbishment completely on the whole truck parts, like engines, alxes, transmissions, cabins, etc. After refurbishment, used howo dump truck will look like a new one with top working conditions. Acturally our used howo trucks can be used for another 5 to 10 years under regular maintenance. However, some trucks maybe need to be repaired after 3 or 5 months working. That’s because of inappropriate operation. So please run your trucks following below notice.
Running-in Notice
1. After the engine starting, do not accelerate immeditely; increase the engine speed when reaching the normal using temperature.
2. Drive the vehicle on the fat road in breaking-in period.
3. Change the gear timely, make the clutch smooth engagement, and avoid to sudden accelerate or brake.
4. Change into the low-grade before uphill; do not let the engine work at a very low speed.
5. The vehicle is not driven at high speed when full-loading. Pay attention to every indicating signal and warning light.
6. Exam and control the nomal temperature of cooling fluid and grease pressure. Pay attention to the temperature of gearbox, front and rear axle, wheel-hub and brake drum. If serious heating, find the reason, adjust and repair it immediately.
7. After changing the wheels, tighten the wheel nuts according to the set torque.
USED HOWO TRUCKS SPECIFICATIONS
| Truck Model |
ZZ3257N3847C |
| Driving Style |
Left Hand Driving/Right Hand Drive |
| Dimension(Lx W x H)(unloaded)(mm) |
8265x2496x3490 |
| Cargo body size (L*W*H, mm) (mm) |
5400x2300x1500mm 18.63m3 |
| Cargo thickness(mm) |
Bottom:8mm, Side:6mm |
| Lift type of Carriage |
Middle lifting system |
| Approaching angle/Departure angle(°) |
20/26 |
| Overhang(front/rear) (mm) |
1540/1750 |
| Wheel base (mm) |
3625+1350 |
| Max speed(km/h) |
78 |
| Curb weight(kg) |
12270 |
| Loading Weight(kg) |
30,000 |
| Fuel tanker capacity(L) |
300 |
| Clutch |
Single-plate dry clutch Φ430mm |
| Engine Model |
Fuel type |
Diesel |
| Horse Power, max(kw/rpm) |
371HP/375HP/420HP |
| Emission |
EURO II |
| Model |
WD615.47,water-cooled,four strokes,6 cylinders in line with water cooling , electric injection |
| Transmission |
Model |
HW19710, 10 forwards and 2 reverse |
| Brake system |
Service brake |
Dual circuit compressed air brake |
| Parking brake |
spring energy, compressed air operating on rear wheels |
| Auxiliary brake |
Engine exhaust brake |
| Steering system |
Model |
ZF8118 hydraulic steering with power assistance |
| Front axle |
HF9 , Steering with double T-cross section beam |
| Rear axle |
HC16, Pressed axle housing, central double reduction with differential locks between axles and wheels |
| Color |
Optional (White ,Red ,yellow ) |
| Tyre |
12.00R20 radial tires, 10+1pcs |
| Electrical system |
Battery |
2X12V/165Ah |
| Alternator |
28V-1500kw |
| Starter |
7.5Kw/24V |
| Cab |
HOWO76 Cab , single sleeper with air conditioner |
|
Shipping
Before delivery, we can wax and repaint all the trucks to ensure that each truck in your hands can play the maximum efficiency, which can save your money and time. And then improve your life.
Bulk Ship
Flat Rack Container
Ro-Ro Ship
Our Workshop:
Howo Truck Details
Export Record:
Howo 371hp dump truck used in Ghana
3 units Howo dump truck to Congo
6 units Howo dump truck to Senegal
20 units of Dump truck to Malawi, ETS Company
