Sand Transport Tri Axle End Dump Trailer 40 Ton 50 Ton

Large Image : Sand Transport Tri Axle End Dump Trailer 40 Ton 50 Ton

Product Details:

Place of Origin:	CHINA
Brand Name:	ALSTON
Certification:	CCC, ISO, CE
Model Number:	ATM3316DT

Payment & Shipping Terms:

Minimum Order Quantity:	1 unit
Price:	$16000-$22000
Packaging Details:	Nude, Waxing before delivery
Delivery Time:	15-30 working days
Payment Terms:	T/T, L/C, Western Union
Supply Ability:	30 units per month

Contact Now

Sand Transport Tri Axle End Dump Trailer 40 Ton 50 Ton

Description

Product Name:	Rear Dump Trailers	Axle:	3 Axle
King Pin:	2"(50mm)or3.5"(90mm) JOST	Tyre:	12R22.5
Dimension:	9600x2550x3860mm	Loading Capacity:	40tons 50tons
Highlight:	40T tri axle end dump trailer , tri axle end dump trailer , tri axle end dump trailer 40T 50T

Dump Trailer 40tons 50tons Sand Transport 3 Axle Rear Dump Semi Trialer

Rear Dump Trailers Features:

The dump semi trailer adopts a rearward tipping method. It can improve the transportation efficiency of bulk cargo.

The hydraulic tipper trailer’s frame and the longitudinal carriage are welded by high-quality manganese plates.
The tipper trailers cargo has both U-shaped and rectangular type. The dimension can be designed according
to the payload.
The end dump trailers’ main components are machined by advanced equipment. The dump trailer stringer
is fully welded, accurate assemble axles and leaf springs by using an assembly machine.

REAR DUMP TRAILERS SPECIFICATIONS

	Model	3 axle 60ton Rear Dump Trailer
	Function	Transport sand, stone, gravel
Dimension
	Overall Size (L×W×H)mm	9600×2550×3860mm
	Inner Size (L×W×H)mm	8300×2330×2000mm
	Wheel base	6870+1310+1310mm
Weight
	Payload	68,000kg
	Tare weight	Approx12,000kg
	G.V.W.R.	Approx 80,000kg
Body details
	Main beam	Material Q345 carbon steel, upper plate 18mm, down plate 18mm, middle plate 8+8mm.
	Body thickness	6mm
	Bottom thickness	8mm
	Hydraulic System	Full set of HYVA Hydraulic System 202
Frame
	Axle	heavy duty, 3×13Ton capacity, FUWA brand
	Suspension	Leaf spring suspension, 90mm×16mm×10pcs
	Tire	12R22.5 12units Taitong Brand
	Kingpin	50mm/90mm removable
	Landing gear	Yahua brand, 28ton, double speed, heavy duty
	Tool box	1pcs
	Spare wheel carrier	2pcs

Sand Transport Tri Axle End Dump Trailer 40 Ton 50 Ton 0

Flat Rack Container Bulk Ship

Sand Transport Tri Axle End Dump Trailer 40 Ton 50 Ton 1
