60T 80T Rear Dump Trailers , 4 Axle Rear Tipper Trailer 35m3 40m3

60T 80T Rear Dump Trailers , 4 Axle Rear Tipper Trailer 35m3 40m3
60T 80T Rear Dump Trailers , 4 Axle Rear Tipper Trailer 35m3 40m3 60T 80T Rear Dump Trailers , 4 Axle Rear Tipper Trailer 35m3 40m3 60T 80T Rear Dump Trailers , 4 Axle Rear Tipper Trailer 35m3 40m3 60T 80T Rear Dump Trailers , 4 Axle Rear Tipper Trailer 35m3 40m3 60T 80T Rear Dump Trailers , 4 Axle Rear Tipper Trailer 35m3 40m3 60T 80T Rear Dump Trailers , 4 Axle Rear Tipper Trailer 35m3 40m3

Large Image :  60T 80T Rear Dump Trailers , 4 Axle Rear Tipper Trailer 35m3 40m3

Product Details:
Place of Origin: CHINA
Brand Name: ALSTON
Certification: CCC, ISO, CE
Model Number: ATM3316DT
Payment & Shipping Terms:
Minimum Order Quantity: 1 unit
Price: $16000-$25000
Packaging Details: Nude, Waxing before delivery
Delivery Time: 15-30 working days
Payment Terms: T/T, L/C, Western Union
Supply Ability: 30 units per month
Contact Now

60T 80T Rear Dump Trailers , 4 Axle Rear Tipper Trailer 35m3 40m3

Description
Product Name: Rear Dump Trailers Type: Truck Trailer
Suspension: Mechanical Suspension Axle: 4 Axle
Landing Gear: JOST Brand Two-speed Dimension: 9600x2550x3860mm
Highlight:

80t Rear Dump Trailers

,

80t Rear Dump Trailers

,

Q345B Rear Dump Trailers

60 80 Tons 4 Axles Rear Dump Trailers 35 40 Cubic Meter Rear Tipper Trailers



Rear Dump Trailers Advantages:



Volume and Loading capacity of rear dump trailers can be customized according to customer’s requirements.

Frame body Q345B high strength structure steel.

Well-known brand axles, suspension systems, high performance, and reliable to use.

Alston rear dump trailers are equipped with HYVA cylinder, which is more reliable and safer.

Full braking and electrical systems at home and abroad are in accordance with ISO standard, optional ABS

system. Braking and lighting are absolutely safe and reliable.



Production Process
A. Steel auto cutting
B. Main beam auto submerged arc welding
C. chassis reversal
D. shot blasting for rust cleaning
E. Welding by experienced worker
F. Final cleaning welding slag
G. Dust-free painting



                          REAR DUMP TRAILERS SPECIFICATIONS

  Model 4 axle 40m3 rear dump trailer
  Function Transport sand, stone, gravel
Dimension
  Overall Size (L×W×H)mm 9600×2550×3860mm
  Inner Size (L×W×H)mm 8300×2330×2000mm
  Wheel base 6870+1310+1310mm
Weight
  Payload 68,000kg
  Tare weight Approx12,000kg
  G.V.W.R. Approx 80,000kg
Body details
  Main beam Material Q345 carbon steel, upper plate 18mm, down plate 18mm, middle plate 8+8mm.
  Body thickness 6mm
  Bottom thickness 8mm
  Hydraulic System Full set of HYVA Hydraulic System 202
Frame
  Axle heavy duty, 4×13Ton capacity, FUWA brand
  Suspension Leaf spring suspension, 90mm×16mm×10pcs
  Tire 12R22.5 16units Taitong Brand
  Kingpin 50mm/90mm removable
  Landing gear Yahua brand, 28ton, double speed, heavy duty
  Tool box 1pcs
  Spare wheel carrier 2pcs



60T 80T Rear Dump Trailers , 4 Axle Rear Tipper Trailer 35m3 40m3 0

Flat Rack Container                                        Bulk Ship

60T 80T Rear Dump Trailers , 4 Axle Rear Tipper Trailer 35m3 40m3 1

60T 80T Rear Dump Trailers , 4 Axle Rear Tipper Trailer 35m3 40m3 2

60T 80T Rear Dump Trailers , 4 Axle Rear Tipper Trailer 35m3 40m3 3

Other Related Semi Trailers:

60T 80T Rear Dump Trailers , 4 Axle Rear Tipper Trailer 35m3 40m3 4

60T 80T Rear Dump Trailers , 4 Axle Rear Tipper Trailer 35m3 40m3 5
